Reefer container for transportation and stationary storage of Pfizer-BioNTech coronavirus vaccine BNT162b2 (COVID-19)
We offer reefer containers 20' feet and 10' feet designed by the worlds leading manufacturer of the climatic technology ThermoKing Ingersoll Rand company supposed to be used for transportation and further storage of the vaccines with maintaining temperatures up to -40 and -70 depending on the requirments of the vaccine manufacturer.
The containers are available in Europe (Antwerp, Belgium) and China (Shanghai).
Containers can be delivered by air, sea and road transport, depending on the location and the customer's demand. We offer air delivery of containers by Ruslan planes of Antonov Airlines Company. For one flight Ruslan aircraft of Antonov Airlines can take on board up to 12 containers of 20 feet with a volume of 24.5 m3. up to 28 m3.
We can offer sea freight by CMA-CGM, ZIM, OOCL, MAERSK and others leading shipping lines, depending on the best service in the direction of the customer's port.
We offer Thermoking gensets to provide container power supply during the transport of COVID-19 vaccine Pfizer-BioNTech by road.
The gensets can also be used during emergency power off during stationary storage of the vaccine BNT162b2.
At the moment, SUPER-FREEZER containers can be used not only for stationary storage of the vaccine and transportation of the vaccine within the country, but also can be used to transport the vaccine from the manufacturer's plant to the buyer's warehouse by road, sea transport, as well as solution for the transportation of the vaccine by air in SUPER-freezer containers is in progress.
For a detailed calculation of the cost of transporting a vaccine BNT162b2, we need
Warehouse address
loading
Warehouse address
discharge
Size and weight
tare
Loading time
of containers with vaccine
Time for return
containers to the airport
after discharge
E-mail: servicemanager@refholod.com.ua
Phone: +38 (093) 080 06 06
You can find detailed technical information about containers, gensets and aircraft in the documentation attached to this page, or you can request from our managers using the contacts in the site header or above in the article.
Technical data and specifications from this article
Container SUPERFREEZER for ultra low temperatures
Specifications
| ENGINE | TK Diesel engine 30,1 hp, mechanical direct injection, naturally aspirated with closed crankcase ventilation |
| FUEL | TYPE No. 2 diesel (under normal conditions) / No. 1 diesel (cold weather fuel) |
| ROTATIONAL SPEED | 1890 +10rpm / 1560 +10-Orpm |
| GENERATOR | 460/230Vac, 3Phase, 60HZ |
| OUTPUT POWER | 15kW. |
| APPARENT POWER | 18.75 kVA |
| ROTATIONAL SPEED | 1800rpm |
| ELECTRICAL SYSTEM | SG+1.5 microprocessor controller |
| BATTERY | 12V, 925 CCA at -18°C (0°F) |
| FUEL TANK | Included in all models |
| SG CLIP-ON SG CENTRE-MOUNT SG SIDE-MOUNT | 4731 (125gal) 302I or 1981 (80gal or SOgal) 2831 (75gal) |
SUPER FREEZER REFRIGERATION UNIT
| General: | |
| Unit type: | Ultra-Low temperature unit. Cascade system with dual refrigeration circuit R134a with Copeland 3 cylinder compressor. Charge 3.5 kg (7.7 lbs) R23 with Copeland Scroll compressor. Charge 3.2 kg (7.0 lbs) |
| Setpoint Range: | -70°C to -10°C (-94°F to -14°F) |
| Ambient temperature Range: | -30°C to +37.8°C (-22°F to 100°F) |
| Required heat leakage of 10' box: | 18 Watt/°K @ 20C wall temperature, to ensure set-point at ambient 20 Watt/°K |
| Required heat leakage of 20' box: | 20C wall temperature, to ensure set-point at ambient |
| Container protection | Pressure equalization valve to avoid excessive vacuum in the container |
| Cooling Capacity @ ambient temperature +37.8°C (100°F) | ||
| At setpoint -30°C (-22°F) | 8,250 watt @ 460V/60HZ | 7,112 watt @ 400V/50HZ |
| At setpoint -60°C (-76°F) | 5,850 watt @ 460V/60HZ | 5,086 watt @ 400V/50Hz |
| At setpoint -70°C (-94°F) | 3,880 watt @ 460V/60HZ | 3,344 watt @ 400V/50HZ |
| Electricity: | |
| Power supply: | A/C 400 to 500 Volt 3 phase 60 Hz ±2,5% A/C 360 to 460 Volt 3 phase 50 Hz ±2,5% |
| Main circuit breaker: | 32 Amp |
| Power cable: | 18.3 m (60 LF) cable (3phase and ground) with CEE17 power plug (32 Amp; ground 3h) |
| Maximum power draw: | 19 kw during "pull down" |
| Required heat leakage of 20' box: | 20C wall temperature, to ensure set-point at ambient |
| Container protection | Pressure equalization valve to avoid excessive vacuum in the container |
| Controller: | Advanced Microprocessor MP3000 control system Temperature control using 6 NTC sensors Temperature accuracy: +/- 1°C (+/-1-8°F) Datalogger document system parameters and changes, results of Pre-Trip Inspections, Alarms & messages, as well as temperature logs. Temperature logs are defaulted to 1 hour interval, and user can change to 30 min, memory allow 15,000 temperature logs 3 USDA cargo sensor ports with Cannon receptacles Telematics (option) to allow two-way communication with controller. Using Global Network Satellite System and Global cellular LTE, 2G, 3G signal) Datalogger can be retrieved via serial port on unit, or via Telematics Defrost: utilizing electical defrost heaters, with timer and on demand |
| Noise level: | 80db (A) in 250 Hz band, mesured in front of the unit at 1.5 m distance |
| Certifications and design standards: | IS01496-2; CE; ATP; AHRI; USDA; HR |
| Weight of SuperFreezer unit: | 630 kg | (1,390 lbs) | (1,390 lbs) | (1,390 lbs) |
| Weight of 10'container incl unit: | 12,000 kg | (24,000 lbs) | Payload: 8,750 kg | (19,290 lbs) |
| Weight of 20'container incl unit: | 24,000 kg | (52,910 lbs) | Payload: 19,500 kg | (42,990 lbs) |
Airplane Ruslan from Antonov Airlines
| AN-124-100 | AN-124-100M-150 | |
| Maximum Payload | 120.00Ckg (2£4,555lbs) | 150X00 kg (330.693lbs) |
| Maximum Votumo | 1.040 CBM | 1.040 CBM |
| Cargo CaMn LWH | 36.Sx6.4x4.4m (1437x25l.9x1732in) | 365x6.4x4.4m (1437x25V9x1732in) |
| including Ran* | 43.7x6.4x44m (18779x251 9x1732m) | 43.7x6.4x4 4m (18779x251.9x1732m) |
| Cargo Door WH | 6.4x4.4m (251.Sx173.2inl | 6.4x4.4m (2S1-Sx173.2m) |
| On-Board Crarto | 30.00Ckg Irft 9(66.139lbs) | 30.00Ckg Irft 66.139lbs) |
Gensets SGCO 3000
818 kg (1804 Ibs) - Total Weight,
including genset, oil, coolant, dry
fuel tank and battery. Genset to be
provided with decal indicating gross
weight inclusive of fuel.
